Commercial Flexible Curtain Track
Get ready to make a circle with our Flexible Curtain Track.
Track Dimensions: 7/16″ wide x 7/8″ tall
Why Choose Our Flexible Curtain Track?
- Easy Installation: Do-it-yourself-friendly; just cut with a hacksaw to size.
- Highly Flexible: Bends to any angle to fit the layout and shape of a curvature.
- Smooth Gliding: Carries substantial load-bearing capacity.
- Durable: Patented structural design; made with exceptional-quality materials and a superior finish.
- Easy to Handle and Store: Transportable or store-able in rolls.
Can your flexible curtain track be used for straight run application?
Without a doubt, our flexible curtain track can also be used for straight run but it will be different from straight track since it has been coiled up. In straight run application, we recommend installing mounting hardware at 9″ interval, with even spacing to make it look better. All mounting hardware need to line up, slightest off set will result in having a wavy track.
When straightness of track is a priority, we have available cubicle curtain aluminum track.
What parts are required for each foot of track?
We recommend 4 rollers per foot of track to avoid curtain from too much sagging. For flexible curtain track mounting hardware, we recommend one per foot for curved track, and 9″ interval for straight run application. If your ceiling or wall is sharply curved, add additional mounting hardware at point of turns. For aluminum track, it needs 30″-36″ each.
How flexible are your tracks?
Our tracks have metal plates embedded, they are extremely flexible and can bend 90 degrees or more without any splice so that the sliders can move freely without interruption. The diameter of a circular standard track can be as small as 12″.
Are your tracks ceiling mounted or wall mounted?
Our tracks can be installed on either ceilings or walls. We offer unique hardware for each. When placing an order, please specify whether the application is intended for ceiling mount or wall mount.
What are your tracks and various components made of?
The track and its parts are made of resin, which is very long lasting. The metal plate embedded within the track is made of steel. Life expectancy is 2 decades.
How long can a single track piece be ordered? Do you sell connector pieces?
Our tracks are up to 164ft continuously without any splices or connectors. We do not sell connector pieces.
What is the weight capacity for standard, medium, and heavy duty tracks?
Optimum weight supporting capacity is 40 pounds per foot of standard track (4 rollers). Medium and heavy duty tracks are relatively greater. Material surface hardness is greater or equal to 75 HA. Softening point is 80 degree C. Life expectancy is 2 decades.
Can your tracks be bent into an S shape? How curved can your tracks be bent?
Indeed, our tracks can be easily bent into S shapes as long as the mounting cartridges are positioned correctly. Our tracks trails tend to be hugely flexible and can bend 90 degrees or more without any splice so that the sliders can move freely without interruption. For example, the diameter of a circular standard track can be as small as 12″. Pertaining to installment directions, click installation on our web.
